12VDC Portable System

By / January 9, 2017

12VDC Portable System Home System

12VDC Portable solar system for Home
Small Home
12VDC and 220VA/C
multipal dc ports
suitable for areas where no grid/wapda
easy installation any on can install by himself. we can give you best prices for 12vdc home system in Pakisan.

12VDC Portable System: Your Complete Guide

A 12V DC portable solar system is a compact, versatile power solution perfect for providing electricity on-the-go without needing an inverter. Here’s everything you need to know about building or buying one.

What is a 12VDC Portable System?

It’s a self-contained setup that generates, stores, and delivers 12V Direct Current (DC) power. Unlike household systems, it stays at low voltage DC—making it simpler, safer, and more efficient for direct device charging and running 12V appliances.

Core Components 12VDC Portable System

  1. 12V Solar Panel(s): 50W to 200W, usually foldable or semi-flexible.

  2. Solar Charge Controller (PWM is common): Regulates power from panel to battery.

  3. 12V Battery (Deep Cycle): AGM, Gel, or LiFePO4 (lightweight, recommended).

  4. Wiring & Connectors: MC4 cables, alligator clips, USB ports, 12V car sockets.

  5. Protection: Fuses and possibly a battery monitor.

Common Uses & Applications 12VDC Portable System

  • Camping & Overlanding: Run LED lights, portable fridges, charge phones.

  • Power Outages (Emergency Backup): Keep phones, radios, and small LED lights running.

  • DIY Projects & Hobbyists: Powering ham radios, cameras, sensors, or small tools.

  • Boats & RVs: Supplemental power for lighting and small electronics.

Key Advantages 12VDC Portable System

  • Portability: Lightweight and easy to transport.

  • Simple Setup: No complex wiring or permits required.

  • High Efficiency: No conversion loss from DC to AC (inverter loss).

  • Safety: Lower voltage (12V) is generally safer to handle than high-voltage AC systems.

  • Affordability: Lower cost than full AC systems with inverters.

How to Build a Basic 100W 12V Portable System (Example)

Sample Setup for a Weekend Trip:

  1. Panel: 100W foldable solar panel with a built-in kickstand.

  2. Controller: 10A PWM charge controller.

  3. Battery: 50Ah LiFePO4 battery (weighs ~6 kg vs. 15+ kg for lead-acid).

  4. Outputs: A distribution box with 2x USB ports, 1x 12V car socket, and terminal posts.

  5. Runtime: Can charge a phone ~25 times or run a 12V camping fridge for ~12 hours.

Wiring Order:
Solar Panel → Charge Controller → Battery → Your 12V Devices

Buying Guide: Pre-Made Kits vs. DIY

Option Pros Cons
Pre-Made Kit (e.g., Jackery, Bluetti, EcoFlow) All-in-one, plug-and-play, sleek design, integrated battery management. More expensive per watt, proprietary parts, less customizable.
DIY Build More affordable, fully customizable, repairable, uses standard components. Requires basic electrical knowledge, less polished look, more assembly time.

Important Safety & Performance Tips

  1. Always Use a Charge Controller — never connect a panel directly to a battery.

  2. Match Voltages: Ensure panel Vmp (~18V) is suitable for charging a 12V battery.

  3. Fuse Your Connections: Place a fuse (e.g., 15A) on the positive wire between battery and devices.

  4. Lithium Over Lead-Acid: For portability, choose LiFePO4 — lighter, longer-lasting, and maintenance-free.

  5. Calculate Your Needs: Add up the watt-hours (Wh) your devices use daily to size your battery and panel correctly.





Sample Cost Estimate (DIY)

  • 100W Foldable Panel: ₨ 15,000 – 25,000

  • 10A PWM Controller: ₨ 2,000 – 4,000

  • 50Ah LiFePO4 Battery: ₨ 25,000 – 40,000

  • Cables & Accessories: ₨ 3,000 – 5,000

  • Total Approx.: ₨ 45,000 – 74,000

(Prices vary by brand and quality in Pakistan.)





Absolutely. A 12V DC portable solar system is a compact, self-contained power bank that uses solar panels to generate and store electricity in a 12V battery. It’s perfect for charging phones, running LED lights, and powering small 12V devices during camping, road trips, or power outages without needing a bulky inverter. Easy to set up and transport, it provides essential off-grid power anywhere.



Final Recommendation

A 12V DC portable system is perfect for mobile, small-scale power needs. For most users, a pre-made power station paired with a folding solar panel offers the best balance of convenience and performance. For hobbyists or budget-focused users, a custom DIY setup provides maximum flexibility and value.
