20kw on grid solar system Configuration
Core Components
| Component | Specification |
|---|---|
| Solar Panels | 34 × LONGi HIMO 6 (LR5-72HBD-615M) |
| Total DC Capacity | 20.91kW (615W × 34) |
| Inverter | AUXsol AS-20000 (20kW 3-phase) |
| Mounting Structure | H Beam elevated |
| Daily Output (Summer) | 80-100 kWh |
| Annual Generation | ~29,000-35,000 kWh |
Technical Specifications of 20kw on grid solar system
1. LONGi HIMO 615W Panels
-
Type: Mono PERC Bifacial
-
Efficiency: 22.3%
-
Dimensions: 2279×1134×30mm
-
Weight: 28.5kg/panel
-
Temperature Coefficient: -0.35%/°C
2. AUXsol AS-20000 Inverter
-
MPPT Range: 450-850V
-
Max Input Current: 26A per MPPT
-
Efficiency: 98.2%
-
IP Rating: IP65 (Outdoor)
-
Warranty: 10 years
3. Elevated Structure
-
Height: 2m ground clearance
-
Material: Iron H Meam
-
Wind Rating: 120km/h
-
Tilt Angle: 15°-30° (optimized for Pakistan)
20kw ongrid solar system Pricing Breakdown (PKR)
| Item | Cost (PKR) |
|---|---|
| 34 × LONGi 615W panels | 650,000 – 700,000 |
| AUXsol 20kW inverter | 250,000 – 290,000 |
| Elevated structure | 300,000 – 425,000 |
| Installation & wiring | 300,000 – 400,000 |
| Total System Cost | 1500,000 – 1630,000 |
Prices vary by location and installer
System Performance
| Scenario | Output |
|---|---|
| June (Lahore) | 110-120 kWh/day |
| December | 60-70 kWh/day |
| Annual Savings | PKR 1.8-2.2 million (@PKR 18/unit) |
Key Advantages
-
High-Efficiency Combo
-
LONGi’s bifacial gain (+10-15% in elevated setup)
-
AUXsol’s dual MPPT for shading mitigation
-
-
Structural Benefits
-
Allows under-panel space utilization (parking/agriculture)
-
Better airflow = 3-5% cooler panel temps
-
-
Commercial Viability
-
Payback period: 3.5-4.5 years
-
30+ year lifespan
-
Critical Considerations
-
Net Metering Approval required for grid connection
-
Soil Testing mandatory for elevated structures
-
Lightning Protection recommended for tall mounts
Installation Requirements
-
Electrical
-
3-phase grid connection
-
200A main breaker
-
4mm² DC cables
-
-
Civil Works
-
12-16 concrete foundations (1.5m depth)
-
-
Certifications
-
NEPRA generation license
-
Where to Buy?
-
LONGi Panels:
-
Pakistan Solar Traders (Lahore)
-
-
AUXsol Inverters:
-
Pakistan Solar Traders
-
Professional Support
For a customized feasibility study, provide:
-
Site location
-
Recent electricity bills
-
Soil test report (if available)
Contact: 0304-1111988
This 20kw on grid solar system is ideal for:
✔ Factories ✔ Agricultural pumps ✔ School/universities ✔ Car parking shades
