Dyness | Low Voltage LiFePO4 Storage
Dyness PowerBrick SC — 51.2V 314Ah 16.07kWh Lithium Battery in Pakistan
The Dyness PowerBrick SC is a premium-grade, wall-mounted LiFePO4 lithium battery built for residential and commercial solar energy storage. With a massive 16.07kWh nominal capacity at 51.2VDC and 314Ah, it delivers deep, reliable backup power for homes, offices, and hybrid solar systems across Pakistan.
Rated IP20 for indoor installation and engineered for long-term daily cycling, the PowerBrick SC combines intelligent BMS, integrated Wi-Fi monitoring, aerosol fire protection, and broad inverter compatibility — making it one of the most capable low-voltage batteries available in Pakistan today.
✔ 8000+ Cycles
✔ IP20 Indoor Rated
✔ Hybrid Inverter Ready
✔ 10-Year Warranty
Nominal Energy
Nominal Voltage
Rated Capacity
Cycle Life @80% DOD
Indoor Protection
Battery Warranty
Dyness PowerBrick SC — Product Overview
The Dyness PowerBrick SC is part of Dyness’s widely respected PowerBrick low-voltage battery family — a range trusted by solar installers and homeowners globally for its modular design, consistent performance, and long cycle life. The SC variant is specifically engineered for indoor residential and commercial installations, rated IP20 for controlled indoor environments.
At its core, the PowerBrick SC uses premium LiFePO4 (Lithium Iron Phosphate) cell chemistry — the most stable and safest lithium chemistry available for solar energy storage. LiFePO4 does not overheat, does not experience thermal runaway, and performs reliably through thousands of deep charge-discharge cycles, making it the industry standard for quality solar batteries in Pakistan and worldwide.
With 314Ah at 51.2V, the PowerBrick SC delivers 16.07kWh of nominal energy — enough to power a well-equipped Pakistani home through long load shedding hours. It is compatible with a wide ecosystem of hybrid inverters through CAN bus and RS485 communication protocols, including Solis, Goodwe, Growatt, Deye, Luxpower, Victron, SMA, and more. Explore our full lithium battery range or compare on our lithium battery price page.
The PowerBrick SC is a scalable storage solution. Multiple units can be connected in parallel to expand total storage capacity from 16kWh up to hundreds of kWh — ideal for large homes, multi-story buildings, offices, shops, factories, and commercial solar projects that require reliable, extended backup power in Pakistan’s challenging grid conditions.
Key Features of the Dyness PowerBrick SC 16kWh Battery
Every detail of the PowerBrick SC has been engineered to deliver maximum reliability, safety, and ease of use in real-world residential solar applications.
Massive 16.07kWh Capacity
With 314Ah at 51.2V, the PowerBrick SC stores substantially more energy than standard 100Ah or 280Ah batteries, making it one of the highest-capacity single-unit low-voltage batteries available in Pakistan. It eliminates the need for multiple smaller batteries in most residential setups.
High Continuous Discharge Power
The PowerBrick SC supports a maximum continuous discharge current of 157A, delivering up to 8kW+ of continuous power. This is sufficient to run air conditioners, refrigerators, water pumps, and multiple appliances simultaneously without any performance degradation.
Advanced Intelligent BMS
An integrated Battery Management System (BMS) continuously monitors cell voltage, temperature, state of charge, and current. It provides overcharge, over-discharge, over-temperature, short-circuit, and cell imbalance protection — ensuring maximum safety and cell longevity through every cycle.
Aerosol Fire Suppression System
The PowerBrick SC includes an intelligent aerosol fire extinguishing module that automatically detects and suppresses internal thermal events within approximately 5 seconds. This is a critical safety feature that distinguishes Dyness batteries from cheaper alternatives, providing genuine protection for your home and family.
Integrated Wi-Fi Monitoring
A built-in Wi-Fi module with cloud connectivity enables real-time monitoring of battery status, charge level, health data, and performance history through the Dyness mobile app. OTA (Over-the-Air) firmware updates ensure your battery stays current without requiring physical service visits.
Wide Inverter Compatibility
The PowerBrick SC communicates via CAN bus and RS485 protocols, making it compatible with a broad range of hybrid inverters used in Pakistan including Solis, Growatt, Goodwe, Deye, Luxpower, Victron, SMA, Sungrow, Voltronic, Ingeteam, and more — giving installers and users maximum flexibility.
Fully Scalable — Parallel Expansion
The PowerBrick SC supports parallel connection of up to 50 units, allowing total system capacity to scale from 16kWh to over 700kWh+. Whether you start with a single unit today and add more later, or deploy a full commercial battery bank from day one, the PowerBrick SC adapts to your requirements without compatibility issues.
8000+ Cycles — 10-Year Service Life
Rated for over 8,000 charge-discharge cycles at 80% depth of discharge, the PowerBrick SC is engineered for over a decade of daily cycling. Combined with a 10-year manufacturer warranty, this battery delivers exceptional lifetime value compared to lead-acid alternatives that typically last only 2–4 years.
IP20 Indoor Installation
The PowerBrick SC carries an IP20 ingress protection rating, making it suitable for indoor installation in technical rooms, basements, utility spaces, and dedicated battery rooms. Its modular, wall-mountable or floor-standing design ensures a clean, space-efficient installation footprint in any indoor solar setup.
Dyness PowerBrick SC — Full Technical Specifications
The table below lists the key electrical, mechanical, and communication specifications for the Dyness PowerBrick SC 51.2V 314Ah 16.07kWh IP20 battery module.
| Electrical Specifications | |
|---|---|
| Battery Type | LiFePO4 (Lithium Iron Phosphate) |
| Nominal Voltage | 51.2 VDC |
| Nominal Capacity | 314 Ah (@0.2C) |
| Nominal Energy | 16.07 kWh |
| Usable Energy (95% DoD) | ~15.27 kWh |
| Depth of Discharge (DoD) | 95% |
| Operating Voltage Range | 43.2 V – 57.6 V |
| Max. Charge Voltage | 57.6 V |
| Max. Continuous Charge Current | 157 A |
| Max. Continuous Discharge Current | 157 A |
| Max. Continuous Discharge Power | ~8.0 kW |
| Recommended Charge Current | 100 A |
| Cycle Life | ≥ 8,000 Cycles @ 80% DoD |
| Round-Trip Efficiency | > 96% |
| Mechanical & Environmental | |
| Ingress Protection Rating | IP20 (Indoor) |
| Installation Type | Wall-mounted / Floor-standing |
| Cell Configuration | 16S1P LiFePO4 |
| Operating Temperature (Charging) | 0°C to +55°C |
| Operating Temperature (Discharging) | -20°C to +55°C |
| Storage Temperature | -20°C to +45°C |
| Humidity | 5% – 95% (non-condensing) |
| Enclosure Material | Cold-rolled steel (powder coated) |
| Communication & Interface | |
| Communication Ports | CAN bus, RS485, RS232 |
| Monitoring | Built-in Wi-Fi, Dyness Cloud App (iOS & Android) |
| App Features | Real-time monitoring, OTA firmware updates, health diagnostics |
| Compatible Inverter Protocols | CAN bus: Solis, Goodwe, Growatt, Deye, Luxpower, Victron, SMA, Sungrow, Schneider, Deye, SAJ, Sunsynk RS485: Voltronic, MPP Solar, Alpha, RCT, Outback |
| Parallel Expansion | Up to 50 units in parallel (716.8kWh max) |
| Safety & Certifications | |
| BMS Protection | Overcharge, over-discharge, over-current, over-temperature, short-circuit, cell imbalance |
| Fire Suppression | Integrated intelligent aerosol fire extinguishing system |
| Certifications | IEC 62619, CE, UN38.3, RoHS |
| Warranty | 10 Years (manufacturer warranty) |
| Design Life | 15+ Years |
Why the Dyness PowerBrick SC is Ideal for Pakistan’s Solar Market
Pakistan’s energy landscape in 2026 continues to be defined by unreliable grid supply, long load shedding hours in both residential and commercial areas, and rapidly rising electricity tariffs. For homeowners and businesses investing in solar systems, a high-capacity, long-life lithium battery is no longer optional — it is the cornerstone of a functional solar installation.
The Dyness PowerBrick SC 16kWh addresses Pakistan’s real-world energy challenges in several important ways. Its 16.07kWh capacity means a single unit can power a medium-to-large household — including fans, lights, refrigerator, WiFi, television, and moderate air conditioning — through 8–12 hours of load shedding without any compromise in comfort. For larger homes or offices with heavier loads, two or more units can be paralleled to double or triple backup capacity.
Unlike conventional lead-acid batteries that require regular water top-ups, degrade rapidly in Pakistan’s heat, and need replacement every 2–3 years, the PowerBrick SC offers a genuine 10+ year service life with zero maintenance. Its LiFePO4 chemistry remains stable even in high ambient temperatures, which is critical for Pakistani summers where temperatures regularly exceed 40°C in battery rooms or technical spaces.
The PowerBrick SC’s wide inverter compatibility is particularly valuable in Pakistan’s diverse solar market, where popular hybrid inverters from Solis, Growatt, Goodwe, Deye, and Luxpower are widely deployed. CAN bus and RS485 communication ensure intelligent charging coordination, preventing overcharge and maximizing solar self-consumption. Visit our Dyness battery product page or browse our full lithium batteries collection for more options and current pricing.
PowerBrick SC LiFePO4 vs Lead-Acid Battery — Why Lithium Wins
Many customers ask whether the Dyness PowerBrick SC justifies its cost compared to a conventional lead-acid battery bank. The table below makes the comparison clear across the metrics that matter most for solar backup in Pakistan.
| Feature | PowerBrick SC (LiFePO4) | Lead-Acid Battery |
|---|---|---|
| Usable Capacity | 95% DoD (~15.27kWh usable) | 50% DoD (8kWh usable from 16kWh) |
| Cycle Life | 8,000+ cycles @ 80% DoD | 500–1,200 cycles |
| Service Life | 10–15 years | 2–4 years |
| Charging Speed | Fast solar charging (157A max) | Slow (10–20% of capacity) |
| Maintenance | Zero maintenance | Monthly water top-up required |
| Temperature Tolerance | -20°C to +55°C stable | Degrades rapidly above 35°C |
| Weight for same capacity | Significantly lighter per kWh | Very heavy (60–70kg per 100Ah/12V) |
| 10-Year Cost (incl. replacements) | Lower overall cost | 3–5× replacements = higher cost |
| Smart Monitoring | Wi-Fi app, BMS, OTA updates | None |
| Fire Safety | Aerosol fire suppression built-in | Acid spillage risk, hydrogen gas |
Who Should Buy the Dyness PowerBrick SC 16kWh Battery?
🏠 Large Residential Homes
Homeowners with higher energy consumption — running 2+ air conditioners, water geysers, refrigerators, and entertainment systems — who want complete independence from load shedding throughout the day and night.
🏢 Offices & Commercial Spaces
Offices, clinics, showrooms, and commercial units that cannot afford power interruptions and need reliable backup for computers, servers, CCTV, lighting, and climate control during load shedding hours.
🏪 Shops & Retail Outlets
Retail businesses that lose sales revenue during every load shedding event and need a dependable, low-maintenance storage system that keeps POS systems, display lighting, refrigeration, and fans running continuously.
🔋 Hybrid Solar System Upgrades
Existing solar system owners who are running lead-acid batteries and want to upgrade to a high-performance LiFePO4 storage solution that increases usable capacity, reduces maintenance, and extends solar self-consumption.
🏭 Light Industrial & SME
Small manufacturers, workshops, and SMEs that rely on power tools, machinery, or production equipment and need a scalable battery bank that can be expanded as load requirements grow.
🌿 Off-Grid & Remote Locations
Farm houses, remote properties, guest houses, and locations with limited or no grid access that require a large, reliable, low-maintenance energy storage system to power daily operations from solar.
Inverter Compatibility — Dyness PowerBrick SC in Pakistan
One of the most important factors when selecting a lithium battery in Pakistan is ensuring it communicates correctly with your hybrid inverter. The Dyness PowerBrick SC supports both CAN bus and RS485 communication protocols, giving it one of the broadest inverter compatibility lists of any battery in its class.
CAN Bus Compatible Inverters
RS485 Compatible Inverters
Not sure if the PowerBrick SC works with your inverter? WhatsApp us your inverter model and our team will confirm compatibility instantly.
Explore More Solar Products at Pakistan Solar Traders
Pakistan Solar Traders is Lahore’s leading solar energy supplier. Browse our full range of lithium batteries, hybrid inverters, solar panels, and complete solar systems below.
Ready to Order the Dyness PowerBrick SC in Pakistan?
Send your inverter model, total load, and desired backup hours to Pakistan Solar Traders on WhatsApp or call our UAN for a free consultation, detailed quote, and delivery timeline across Pakistan.
FAQ — Dyness PowerBrick SC 51.2V 314Ah 16.07kWh Battery
What is the Dyness PowerBrick SC and how does it differ from other batteries?
The Dyness PowerBrick SC is a high-capacity, low-voltage LiFePO4 (Lithium Iron Phosphate) residential and commercial energy storage battery rated at 51.2V, 314Ah, and 16.07kWh. It is the SC (Standard Configuration) variant of Dyness’s PowerBrick product family, designed for indoor installation (IP20). Compared to smaller 5kWh or 100Ah batteries, the PowerBrick SC delivers over 3× more energy in a single unit, making it ideal for users with high backup requirements who want a clean, scalable solution without stacking many smaller batteries.
How many hours of backup does the Dyness PowerBrick SC provide?
Backup time depends on your connected load. With a usable capacity of approximately 15.27kWh (at 95% DoD): a 1,000W load (basic home) gets roughly 15 hours of backup; a 2,000W load (moderate AC + appliances) gets about 7–8 hours; a 3,000W load gets approximately 5 hours. For homes with air conditioning, inverter ACs running at 1.5 tons consume approximately 1,200–1,500W, and the PowerBrick SC can sustain one AC plus a full household load for a typical 8–10 hour load shedding window. Contact us on WhatsApp 0300 0644424 with your exact load list for a precise calculation.
Is the Dyness PowerBrick SC IP20 suitable for Pakistan’s climate?
Yes. The IP20 rating means the PowerBrick SC is designed for protected indoor environments — technical rooms, battery cabinets, utility spaces, basements, or dedicated battery areas. In Pakistan, it should be installed in a shaded, well-ventilated indoor location away from direct sun and rain. It operates reliably between 0°C and +55°C during charging and -20°C to +55°C during discharge, which covers Pakistan’s full climate range. If outdoor installation is required, Dyness also offers the PowerBrick PLUS with IP65 rating. Our team can advise on the right installation setup for your location.
Which hybrid inverters are compatible with the Dyness PowerBrick SC?
The PowerBrick SC is compatible with a very wide range of inverters via CAN bus and RS485 communication. CAN bus compatible brands include Solis, Growatt, Goodwe, Deye, Luxpower, Victron, SMA, Sungrow, Schneider, SAJ, Sunsynk, MUST, and others. RS485 compatibility includes Voltronic, MPP Solar, RCT, Alpha, and Outback. In Pakistan’s market, this covers the vast majority of hybrid inverters in active use. For a definitive compatibility check for your specific inverter model, WhatsApp us at 0300 0644424.
Can multiple Dyness PowerBrick SC units be connected in parallel?
Yes. The PowerBrick SC supports parallel connection of up to 50 units, allowing total system capacity to scale from 16.07kWh up to over 700kWh for large residential or commercial applications. In parallel configurations, the master unit is configured via a DIP switch and manages communication for the entire battery bank. This makes the PowerBrick SC an excellent long-term investment — you can start with one unit and expand as your energy needs grow, without needing to replace or reconfigure the system.
What is the cycle life and warranty of the Dyness PowerBrick SC?
The PowerBrick SC is rated for over 8,000 charge-discharge cycles at 80% depth of discharge, which corresponds to more than 10–15 years of daily cycling under normal conditions. Dyness provides a 10-year manufacturer warranty covering defects in materials and workmanship as well as capacity retention above specified thresholds. This warranty is backed by Dyness’s global service network and honored through Pakistan Solar Traders as the authorized supplier. Visit our Dyness product page for warranty registration details.
What is the price of the Dyness PowerBrick SC in Pakistan?
Battery prices in Pakistan vary based on exchange rates, import duties, and market conditions. For the most current price of the Dyness PowerBrick SC 16kWh in Pakistan, contact Pakistan Solar Traders directly. You can WhatsApp us at 0300 0644424, call our UAN 0304 1111988, or visit our lithium battery price page for updated market pricing. We offer competitive pricing, flexible payment options, and nationwide delivery.
Does Pakistan Solar Traders provide installation support for the PowerBrick SC?
Yes. Pakistan Solar Traders provides complete pre-sale consultation, technical compatibility verification, supply, and after-sale support for the Dyness PowerBrick SC in Pakistan. We can help you verify inverter compatibility, system sizing, and installation requirements before purchase. For Lahore-based customers, we can also arrange installation through our certified solar installer network. Contact us on WhatsApp 0300 0644424 or call UAN 0304 1111988 for full support.
