Longi Himo X10

Himo x10 longi solar panel

Himo x10 longi solar panel 645W Monofacial

Longi Himo X10The LONGi Hi-MO X10 645W Monofacial Solar Panel features cutting-edge HPDC cell technology, 22.3% efficiency, and robust durability—ideal for utility, industrial, and commercial-grade solar installations.

Specifications

  • Brand: LONGi Solar
  • Model: Hi-MO X10 LR5-72HTH-645M
  • Panel Type: Monofacial
  • Power Output: 645W
  • Cell Type: N-Type HPDC Monocrystalline
  • Efficiency: Up to 22.3%
  • Cell Configuration: 132 Half-Cut Cells
  • Dimensions: 2384 × 1134 × 30 mm
  • Weight: Approx. 32.3 kg
  • Glass: 3.2mm Tempered AR Coated Glass
  • Frame: Anodized Aluminum Alloy
  • Operating Temp: -40°C to +85°C
  • Power Tolerance: 0 ~ +5W
  • Temperature Coefficient (Pmax): -0.29%/°C
  • Mechanical Load: 5400Pa (Snow) / 2400Pa (Wind)
  • Warranty: 12 Years Product | 30 Years Linear Power Output

LONGi Hi-MO X10 645W – Unmatched Power & Proven Performance

The LONGi Hi-MO X10 645W Monofacial Panel represents a new generation of solar modules with N-type HPDC cell technology, offering improved temperature performance, lower LID, and maximum reliability.

Designed for commercial rooftops, solar farms, and industrial plants, the Hi-MO X10 series provides exceptional power density, which means fewer panels needed for larger output—cutting down on land and BOS costs.

With an impressive 22.3% module efficiency, excellent low-light performance, and a strong 30-year power warranty, this panel is built to perform for decades.

Overview

The Himo X10 is a premium, ultra-high-power solar panel built on Longi’s flagship Hi-MO X10 platform. This module is designed for large-scale commercial and utility solar projects where maximizing energy output and minimizing Levelized Cost of Energy (LCOE) are the primary goals. It represents the pinnacle of Longi’s mass-production technology, pushing the boundaries of power output and efficiency.

Key Specifications

  • Power Output (Pmax): Typically ranges from 605W to 635W, placing it in the ultra-high-power class.

  • Cell Technology: Utilizes Longi’s proprietary HPBC (Hybrid Passivated Back Contact) cell technology. This is a next-generation technology that places all grid lines on the back of the cell, creating a pure, unshaded front surface for maximum light capture.

  • Efficiency: Achieves remarkably high module efficiencies, often 23.3% or higher.

  • Cell & Module Type: Features a 132-cell half-cut cell design in a large-format (approx. 2.4m x 1.3m) frame. This reduces resistive losses and improves performance in partial shading conditions.

  • Voltage: Optimized for large-scale system design with a higher voltage (Voc ~47V) and lower current, which reduces wiring costs and allows for longer string lengths.

Key Features & Advantages

  1. Unmatched Power Density: The 605W+ rating delivers an exceptional amount of power from a single panel, significantly reducing the number of panels, racking components, and labor required for a project of a given capacity.

  2. Superior Efficiency from HPBC: The back-contact cell design eliminates front-side metallization shading, leading to a dramatic increase in light absorption and current generation. This also results in a uniform, all-black aesthetic.

  3. Excellent Reliability & Energy Yield: The HPBC structure offers better resistance to potential-induced degradation (PID) and micro-cracking. Combined with a low temperature coefficient, it ensures high energy harvest over its long lifespan, backed by a 30-year performance warranty.

  4. Optimized for LCOE: For large installations, the Himo X10’s combination of high wattage, high efficiency, and robust performance directly translates to a lower Levelized Cost of Energy, providing a superior return on investment.

Applications

This panel is engineered specifically for:

  • Utility-Scale Solar Farms: Where its high power and efficiency maximize land use.

  • Commercial & Industrial (C&I) Rooftops and Plants: Ideal for large, unshaded roofs where weight and space are key considerations.

Summary

The Himo X10 (Longi 605-635W) is not just a solar panel; it’s a system-level solution for large-scale solar deployment. By leveraging the revolutionary HPBC cell technology, it sets a new benchmark for power, efficiency, and long-term value, making it a top-tier choice for developers and EPCs focused on achieving the lowest possible cost of solar energy.

Himo x10 635 data sheet Mono facial

himo x10 bifacial datasheet 630-650
