Canadian Solar TOPBiHiKu7 705W N-Type Bifacial Solar Panel: Complete Description

Executive Summary

The Canadian Solar TOPBiHiKu7 705W represents the pinnacle of solar panel engineering—a revolutionary N-Type bifacial module that delivers unprecedented 705-watt power output with industry-leading 24.3% efficiency. Designed specifically for utility-scale solar farms and commercial installations, this panel combines cutting-edge TOPCon cell technology with exceptional bifacial performance (>90% bifaciality factor) to maximize energy yield and ROI in demanding applications.

Technical Specifications Overview

Core Electrical Specifications

• Maximum Power (Pmax): 705 W

• Open Circuit Voltage (Voc): 43.0 V

• Short Circuit Current (Isc): 21.2 A

• Maximum Power Voltage (Vmp): 36.0 V

• Maximum Power Current (Imp): 19.6 A

• Module Efficiency: Up to 24.3%

• Power Tolerance: 0 to +5 W

Advanced Technology Features of TOPBiHiKu7 705 watt N-type Bi-facial Canadian

• Cell Technology: N-Type TOPCon (Tunnel Oxide Passivated Contact)

• Cell Configuration: 144 half-cut cells (12×12 matrix)

• Bifacial Design: Double-glass construction with transparent backsheet

• Bifaciality Factor: >90% (exceptional rear-side power generation)

• Temperature Coefficient: -0.29%/°C (superior high-temperature performance)

• NOCT (Nominal Operating Cell Temperature): 41°C

Key Differentiators & Competitive Advantages

1. Unmatched Power Density

At 705W, the TOPBiHiKu7 offers the highest power output per panel commercially available, reducing:

• Balance-of-system costs (fewer panels, racks, connectors per MW)

• Installation time and labor requirements

• Land/roof space requirements by 15-20% compared to 600W alternatives

2.TOPBiHiKu7 705 watt N-type Bi-facial Canadian  Superior Bifacial Performance

• >90% Bifaciality: Industry-leading rear-side efficiency

• Real-World Gains: 5-30% additional energy yield depending on surface albedo

• Optimal Applications: Elevated ground-mount systems with high-reflectivity surfaces (sandy terrain, white membranes, gravel)

3. N-Type TOPCon Advantages Over PERC

• Lower Degradation: <1% first-year degradation vs. 2% for PERC

• Better Temperature Performance: Maintains higher output at elevated temperatures

• Enhanced Low-Light Response: Superior dawn/dusk and cloudy day performance

• Zero LID (Light-Induced Degradation): Eliminates PERC’s initial power drop

4. TOPBiHiKu7 705 watt N-type Bi-facial Canadian Robust Mechanical Design

• Frame: Anodized aluminum alloy with 12 busbars

• Glass: 3.2mm anti-reflective, high-transmission front glass + 2.0mm rear glass

• Dimensions: 2278 × 1134 × 35 mm

• Weight: 32.5 kg

• Load Ratings: 5400 Pa front / 2400 Pa rear

• Fire Rating: Class A (highest available)

Performance & Warranty

Power Output Warranty

• Year 1: 98.5% of nominal power

• Year 30: 87.4% of nominal power (linear degradation)

• 30-Year Linear Performance Guarantee

Real-World Performance Data

• Energy Yield: 5-8% higher than equivalent PERC bifacial panels

• ROI Impact: 10-15% lower LCOE (Levelized Cost of Energy) over project lifetime

• Temperature Performance: Only 8.7% power loss at 60°C vs. 12% for PERC alternatives

Ideal Applications

Primary Markets:

1. Utility-Scale Solar Farms

   • Large ground-mounted installations (10+ MW)

   • High-albedo environments (desert, coastal, snow-prone regions)

   • Tracking system compatibility (single-axis and dual-axis)

2. Commercial & Industrial Rooftops

   • White membrane roofs (enhanced bifacial gain)

   • Large flat commercial buildings

   • Carport solar structures

3. Specialized Applications

   • Agri-photovoltaic systems (crop-compatible installations)

   • Floating solar farms (water surface enhances bifacial gain)

   • Noise barrier integration along highways

Installation Considerations:

• Mounting: Requires specialized racking for 700W+ class modules

• Spacing: Increased rear-side clearance recommended for optimal bifacial gain

• Electrical Design: Higher current requires compatible string inverters (≥20A input)

• Handling: Two-person minimum recommended due to size/weight

Financial & Environmental Impact

Project Economics

• Reduced BOS Costs: ~$0.05/W reduction in overall system costs

• Increased Energy Yield: 5-30% higher than monofacial equivalents

• Shorter Payback Period: 6-18 months faster ROI compared to standard bifacial

• Land Efficiency: 1.2-1.5 MW/acre achievable (vs. 1.0 MW/acre for 600W panels)

Sustainability Credentials

• Carbon Payback: <1 year (faster than industry average)

• Recyclability: 96% recoverable materials

• Manufacturing: Low-carbon production with renewable energy usage

• Certifications: IEC 61215, IEC 61730, IEC TS 62994 (bifacial), UL 61730

Market Positioning

Competitive Landscape Comparison

Value Proposition

For project developers and EPCs, the TOPBiHiKu7 delivers:

1. Highest energy density per square meter

2. Lowest lifetime LCOE in bifacial category

3. Future-proof technology with proven N-Type reliability

4. Bankable manufacturer with global track record

Support & Availability

• Global Distribution: Available through Canadian Solar’s worldwide network

• Technical Support: Dedicated utility-team engineering support

• Lead Times: Typically 8-12 weeks for large orders

• Customization: Frame colors and junction box configurations available

---

Conclusion: The TOPBiHiKu7 705 watt N-type Bi-facial Canadian represents a paradigm shift in solar technology—offering unprecedented power output, exceptional bifacial performance, and superior long-term reliability. For developers seeking to maximize ROI on large-scale projects, this panel delivers measurable advantages in energy yield, space efficiency, and lifetime costs that redefine what’s possible in utility solar.
