Canadian Solar Panel 650 watt

Canadian Solar Panels 640 W to Canadian Solar Panel 665 W

CS7N-640|645|650|655|660|665MS

Better shading tolerance

Module power up to 665 W
Module efficiency up to 21.4 %

Up to 3.5 % lower LCOE
Up to 5.7 % lower system cost

Comprehensive LID / LeTID mitigation
technology, up to 50% lower degradation

Compatible with mainstream trackers,
cost effective product for utility power plant

Better shading tolerance

Canadian 650 Watt Solar Panel Warranty : 12 Year Enhanced Product Warranty on Materials and Workmanship*

Canadian Solar Panel 650 watt 25 Years Linear Power Performance Warranty*

1st year power degradation, no more than 2%
Subsequent annual power degradation, no more than 0.55%

*According to the applicable Canadian Solar Limited Warranty Statement

40 °C lower hot spot temperature,
greatly reduce module failure rate

Minimizes micro-crack impacts

Heavy snow load up to 5400 Pa,
wind load up to 2400 Pa*

Canadian Solar Panels MECHANICAL DATA
Specification Data
Cell Type Mono-crystalline
Cell Arrangement 132 [2 x (11 x 6) ]
Dimensions
2384 ˣ 1303 ˣ 35 mm
(93.9 ˣ 51.3 ˣ 1.38 in)
Weight 34.4 kg (75.8 lbs)
Front Cover 3.2 mm tempered glass
Frame Anodized aluminium alloy,
crossbar enhanced
J-Box IP68, 3 bypass diodes
Cable 4 mm2 (IEC)
Cable Length
(Including Connector)
460 mm (18.1 in) (+) / 340 mm (13.4
in) (-) or customized length*
Connector T4 series or H4 UTX or MC4-EVO2
Per Pallet 31 pieces
Per Container (40′ HQ) 527 pieces
* For detailed information, please contact your local Canadian Solar sales and
technical representatives.
